The PC ultra-miniature circular electrical connectors are used for circuitconnections in radio and electrical equipment. The cable plug is connected tothe socket fixed on the device through a threaded connecting. Devices can alsobe directly plug-in through sockets mounted on each device.Ultra-miniature circular electrical connectors come in sealed and unsealedversions, with plugs and sockets that can have tail attachments. Receptaclecontain pins, while plugs contain holes.

Technical characteristics

Environment tempeature:-60°C ~ +85°C

Vibration acceleration: 5-2500Hz, 15g

Shock acceleration: multiple times at 50g

Working voltage: 200V

Contact resistance: ≤5m Ω

Insulation resistance: >1000MΩ

Insulation strength: 1000V

Mechanical life:250 cycles

Contact diameter: ∅1.0mm
